Specification：
◆ Color: Black
◆Rated Charging/ Discharging Current:10A/20A
◆Max Solar Input Voltage: ＜50V
◆System Voltage: 11.1V/12V/12.8V/22.2V/24V/25.6V
◆Self consume: ＜10mA @12V
◆Float Charging: 12.3V/13.7V/14V/24.6V/27.4V/28V（adjustable)
◆Discharge Reconnect Voltage: 10.5V/12V/12V/21V/24V/24V（adjustable)
◆Discharge Stop Voltage: 9.5V/10.7V/11.2V/19V/21.4V/22.4V（adjustable)
◆Operating Temperature:-20℃~+60℃
◆Material: Aluminum alloy
◆Maximum Wire Size:16AWG
◆Size/Weight: 82x65x22mm/150g
Where you can apply the solar charge controller for?
You can use this solar controller for widely application, like solar monitoring system, solar lighting system, solar fencing system, or solar system for boat and Caravan, and other DIY small solar systems.
What kind of Battery You can Use it to charge：
You can use the solar charge controller for :
ALl kinds of lead acid batteries(including sealed, flooded, AGM and GEL)
3S /6S Lithium ion Battery
4S /8S Lifepo4 Battery
